Description
Product introduction
This product is made by thickening refined mineral oil with lithium hydroxy fatty acid soap, adding anti-oxygen, anti-rust and other additives.
standard：Q/ZTSH-001-2006
Product performance
It has excellent extreme pressure anti-wear property, oxidation stability, water resistance and corrosion resistance.
Application Range
It is widely used in large and medium-sized motor, mineral machinery, textile machinery, automobiles, tractors and other mechanical equipment rolling bearings and sliding bearings and other friction parts of the lubrication.
Operating temperature：-30℃～130℃
Technique Data
|
Items |
Quality Index |
Experimental |
||
|
1# |
2# |
3# |
||
| Appearance |
Yellow smooth uniform ointment |
Visual |
||
| Worked Cone Penetration，0.1mm |
310~340 |
265~295 |
220~250 |
GB/T269 |
| Dropping Point,℃ ≧ |
145 |
150 |
155 |
GB/T4929 |
| Mechanical Impurities, PCS/cm3 Above10μm ≦ |
5000 |
5000 |
5000 |
SH/T0336 |
| Above25μm ≦ |
3000 |
3000 |
3000 |
|
| Above75μm ≦ |
500 |
500 |
500 |
|
| Oxidation Stability（100℃，100h，0.77MPa）Pressure Drop MPa ≦ |
0.070 |
0.070 |
0.070 |
SH/T0325 |
| Steel Mesh Oil Separation（100℃，30h）/% ≦ |
5 |
5 |
5 |
SH/T0324 |
| Evaporation Capacity（99℃，22h）/% ≤ |
2 |
2 |
2 |
SH/T0337 |
| Amount Of Water Leaching（38℃，1h）/% ≦ |
8 |
8 |
8 |
SH/T0109 |
| Corrosion Resistance（52℃，48h） |
1 |
1 |
1 |
GB/T5018 |
Package
10-15kg、170kg
Notice
1.Prevent mixing water and impurities in the process of storage and transportation
2.Do not mix with other greases
3.Do not use after heating
